MagnaClean TwinTech
In central heating systems that have underfloor heating or renewable heating systems using heat pumps, capturing magnetite is one thing but there’s other debris to deal with too. We’ve created MagnaClean TwinTech to handle both. Its high-performance magnet takes care of magnetite, while its fine wire gauze traps non-magnetic and biological films that can build up in these lower temperature systems.
Homeowner Benefits
- Engineered specifically for lower temperature central heating systems such as underfloor heating and renewable heating systems using heat pumps
- Protection from magnetite and non-magnetic debris
- 7% annual saving on heating bills
- Immediate ongoing central heating system protection
- Extends the life of the central heating system
- Reduced carbon emissions
- 2-year warranty when registered within 30 days of installation
Installation and Service Instructions
Maintain peak performance
Whether you’re fitting a MagnaClean® TwinTech on a brand new boiler or retrofitting it on an existing boiler, get the installation right to give the boiler the best protection. And to help keep the filter performing as powerfully as the day it was fitted, service it properly. To do both, simply follow our guide.
Technicial Specifications
Canister and Lid
Material: Glass fibre reinforced nylon
Fluid capacity: 340 ml (chemical bowl)
Inlet diameter: 22 mm at valve
Outlet diameter: 22 mm at valve
Thread: Pressure thread
Flow configuration: Flow must enter the bottom port and exit the top port
Magnet
Housing: Stainless steel
Length: 150 mm
Diameter: 25 mm
Wire Gauze
Material: Stainless steel
Diameter: Approximately 90 mm
Triple Seal Valve
Body material: Nickel plated brass
Seals material: Long life
PTFE ball seals
O ring material: Nitrile 70
Valve inlet/outlet: 22 mm
Bleed Valve
Body material: Nickel plated brass
Screw: Nickel plated brass
Retainer: Nickel plated brass
Ball: Stainless steel
Spring: Stainless steel
Outer hex: 22 mm
Servicing Clearance
Air vent (top): 50 mm
From magnet cap (bottom): 95 mm
Installer Benefits
- Dual-action system protection
- Exceptional magnetic capture
- Stainless steel gauze for efficient biological film removal
- Ideal for use with underfloor heating systems and renewable heating systems with heat pumps
- One-way valve for simple chemical dosing
- Simple installation and servicing
- Follow the flow of arrows on the ports
- The valves can be fitted in any orientation to accommodate different pipework runs, as long as the filter is upright
- MC10+ Biocide is recommended for use with this product
https://youtu.be/2Fn5TpyIIPo?si=7_ytjpAVYNx2XZub
MagnaClean TwinTech in Action
Magnetite can build up in untreated central heating systems, making them inefficient, causing cold spots on radiators and even boiler breakdowns. See how our filter works to remove the sludge and keep boilers working their best
